Reoline Plus Dc-sg/a

REOLINE Laboratory Power Supplies (analog, separate windings)

DESCRIPTION

This portable lab – power supply is a single-phase DC table device with analogue display, separate windings and continuously adjustable output voltage of 0 … 200 VDC. The absolute zero position causes the zero voltage state.

ADVANTAGES

  • Adjustable, low-loss output voltage
  • According to IEC/EN 61558-2-4 IEC/EN 61010-1
  • Mains cable 2m long
  • Illuminated power switch with integrated thermal short-circuit protection
  • Toroidal transformer with absolute zero position
  • Safety socket 4mm at the output
  • Short time overload possible
  • Easy connectivity
  • Does not generate electromagnetic interference
  • Modifications on request
  • Residual ripple 48%
  • Inrush-current limitation optional

TYPICAL APPLICATIONS

  • Laboratory
  • Test field
  • Factory and service applications

TECHNICAL SPECIFICATION
